Protec 6300 - 6.1.7 PRINTING THE DELAY DATA; 6.1.8 CANCELING THE PRINTOUT

93-508-08 Issue 2 Page 17 of 22 Copyright Protec Fire Detection PLC
6300 OPERATING MANUAL
DELAY DATA
ABORT PRINTOUT
NO
6.1.7 PRINTING THE DELAY DATA
Find the ‘DELAY DATA’ option from the printer functions menu using ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
Press ‘ACCEPT’ to print a copy of the full delay matrix and exit back to the ‘Printer Menus’.
Example Delay Data printout: -
To cancel printing, see section 6.1.8 - CANCELING THE PRINTOUT.
6.1.8 CANCELING THE PRINTOUT
Find the ‘ABORT PRINTOUT’ option from the ‘Printer Menus’ using ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
Use ‘NEXT/PREVIOUS’ to toggle between ‘YES’ and ‘NO’. To abort the printout, press ‘ACCEPT’ when the
‘YES’ option is selected. The screen returns to the ‘Printer Menus’.
****************************************
PROGRAM DELAY DATA
09:57:48 16/01/00
INPUT
GROUP OUTPUT GROUP
|
| 01 02 03 04
01 00:00 00:00 00:00 00:00
02 00:00 00:00 00:00 00:00
03 00:00 00:00 00:00 00:00
04 00:00 00:00 00:00 00:00
05 00:00 00:00 00:00 00:00
: : : : :
27 00:00 00:00 00:00 00:00
28 00:00 00:00 00:00 00:00
29 00:00 00:00 00:00 00:00
30 00:00 00:00 00:00 00:00
31 00:00 00:00 00:00 00:00
32 00:00 00:00 00:00 00:00
:
:
INPUT
GROUP OUTPUT GROUP
|
| 29 30 31 32
01 00:00 00:00 00:00 00:00
02 00:00 00:00 00:00 00:00
03 00:00 00:00 00:00 00:00
: : : : :
30 00:00 00:00 00:00 00:00
31 00:00 00:00 00:00 00:00
32 00:00 00:00 00:00 00:00
