Protec 6300 - 6.1.6 PRINTING THE PROGRAM MATRIX

93-508-08 Issue 2 Page 16 of 22 Copyright Protec Fire Detection PLC
6300 OPERATING MANUAL
PRINT MATRIX DATA
6.1.6 PRINTING THE PROGRAM MATRIX
Find the ‘PROGRAM MATRIX’ option from the ‘Printer Menus’ using ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
Press ‘ACCEPT’ and the program matrix will be printed, and exit back to the ‘Printer Menus’.
Program Matrix printout example for output groups 1 to 96: -
To cancel printing, see section 6.1.8 CANCELING THE PRINTOUT.
****************************************
PROGRAM MATRIX DATA
09:57:48 16/01/00
TIMEOUT
| INPUT
| GROUP
| | OUTPUT GROUP
| | 81 83 85 87 89 91 93 95
| | 82 84 86 88 90 92 94 96
:
:
TIMEOUT
| INPUT
| GROUP
| | OUTPUT GROUP
| | 01 03 05 07 09 11 13 15
| | 02 04 06 08 10 12 14 16
00:00 01 C C C C C C C C C C C C C C C C
00:00 02 P P P P C - P P - - - C P P - -
00:00 03 P P P C P C C P P - - - - P P -
00:00 06 P P P P C C P P - - - C P P - P
00:00 07 P P P P P C C P P - - - - P P -
00:00 08 P P P - C C - C C C C C C P - -
00:00 12 P P P - C C - C C C C C C P C -
00:00 13 P P P - C - P C C C C C C P P -
00:00 14 P P P P C C P P - - - C P P - C
00:00 16 P P P - C C - C C C C C C P P -
PULSE ON TIME 03.00 OFF TIME 03.00
MASTER TIMEOUT 00:01
****************************************
