93-508-08 Issue 2 Page 13 of 22 Copyright Protec Fire Detection PLC
PRINT ALL DEVICES ABOVE XX
6.1.2 DEVICES RETURNING ANALOGUE VALUES OUTSIDE A CERTAIN RANGE
Find the ‘ANALOGUE VALUES OUTSIDE LIMITS’ option from the ‘Printer Menus’ using
‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
1) Use ‘NEXT/PREVIOUS’ buttons to scroll through all of the detector type to be printed. Press ‘ACCEPT’.
2) Use ‘NEXT/PREVIOUS’ to select either ABOVE or BELOW. Press ‘ACCEPT’.
3) Set the analogue value to the level of interest using ‘NEXT/PREVIOUS’.
4) Press ‘ACCEPT’ to print. A printout will appear for all loops.
Example printout for ‘ALL’ devices ‘BELOW’ an analogue value of 85: -
To cancel printing, see section 6.1.8 CANCELING THE PRINTOUT.
Press ‘MENU’ to return to the ‘Printer Menus’.
****************************************
LOOP 1 ANALOGUE VALUES BELOW 85
10:45:48 16/01/00
ADDR. DEVICE TYPE CHANNEL 1 CHANNEL 2
VAL AVE. VAL AVE.
01 OPTHEAT 55 58 118 115
02 OPTHEAT 70 70 134 134
06 OPTHEAT 55 58 118 115
11 OPTICAL 55 56
****************************************
