93-508-08 Issue 2 Page 8 of 22 Copyright Protec Fire Detection PLC
ZONE ISOLATED :-
3.3 ISOLATING A ZONE
Find the ‘ISOLATE ZONE?’ option from the ‘Isolation Menus’ using the ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’ to enter the menu option. The LCD displays:
To isolate a zone select the zone to be isolated using ‘NEXT/PREVIOUS’.
Press ‘ACCEPT’ to move the cursor to the ‘NORMAL/ISOLATED’ position.
Pressing ‘NEXT/PREVIOUS’ toggles the zone between NORMAL and ISOLATED states.
Use the ‘MENU’ button to return to the ‘Isolation Menus’.
3.4 VIEWING THE ISOLATED ZONES
Find the ‘VIEW ZONES ISOLATED?’ option from the isolation menus using ‘NEXT/PREVIOUS’ buttons.
On pressing ‘ACCEPT’, if any zones are isolated the LCD displays the first of the isolated zones: -
Pressing either ‘NEXT’ or ‘PREVIOUS’ scrolls through any other zones currently isolated.
If no zones are isolated this function becomes unavailable.
Use the ‘MENU’ button to return to the ‘Isolation Menus’.
