93-508-08 Issue 2 Page 9 of 22 Copyright Protec Fire Detection PLC
NORMALISE ISOLATED ZONES/ADDRESSES
FIRE LINK DISABLEMENT ?
3.5 CLEARING ALL ISOLATIONS
This menu can be used as a quick method to enable all zones and addresses.
Find the ‘NORMALISE DISABLEMENTS?’ option from the ‘Isolation Menus’ using the ‘NEXT’ and
‘PREVIOUS’ buttons. On pressing ‘ACCEPT’ the display shows: -
Pressing either ‘NEXT’ or ‘PREVIOUS’ toggles between the ‘YES/NO’ options available. Pressing ‘ACCEPT’
carries out the selected option and returns the user to the ‘Isolation Menus’. Disablements are normalised on
pressing accept when ‘YES’ is selected.
3.6 FIRE LINK DISABLEMENT / ENABLEMENT
This menu allows the fire link to be disabled or enabled. This facility is not available if it is already provided
by a keyswitch.
Find the ‘FIRE LINK DISABLEMENT?’ option from the ‘Isolation Menus’ using ‘NEXT’ and ‘PREVIOUS’
buttons. On pressing ‘ACCEPT’ the display shows: -
Pressing either ‘NEXT’ or ‘PREVIOUS’ toggles between the ‘YES/NO’ options available. Pressing ‘ACCEPT’
carries out the selected option and returns the user to the ‘Isolation Menus’. The Fire Link will be disabled on
pressing accept when ‘YES’ is selected. Both DISABLEMENT and FIRE LINK DISABLED LED’s will then
be switched on.
Note: On a networked system, the fire link disablement is panel specific.
