Page 7
Kit Simply 230v
Specification
TECHNICAL CHARA
CTERISTIC
MODEL
SIMPLY 230V
Power Supply
230v ~ 50Hz
Current
1,2 - 1,7A
Motor Power
300W
Capacitor
10uF
Thermic Protecti
on
150 Degrees Celsiu
s
Maximum Thrust
280Nm
Class IP Protecti
on
54
Revolutions (speed)
1400 g/m
Working Tempera
ture Range
.
-20 to +55 Degrees Celsiu
s
Leaf's Maximum L
ength
2M
Leaf's Maximum W
eight
250kg
Maximum Opening
Angle (degrees)
130
90 Degree Angle
Opening Time
(sec)
18
Duty Cycle
40%
Kit Simply 230v
Dimensions
6
8
