Protek B8000FD Series User Manual

28
Linearity (1kHz):<0.1%
OUTPUT
channel
Characteristic
A
mplitude: into an open circuit):
2mVpp to 6Vpp(B8040FD)
2mVppto 20mVpp (All other units)
( to 50 Ω): 1mVppto 3Vpp (B8040FD)
1mVpp to10Vpp (All other
units)
Output impedance: 50 Ω
Modulation flatness: 5%
Sine wave flatness: 5%
DC offset: -100%to 100% peak-peak
B OUT
characteristics
Waveform: internal waveforms
A
mplitude (open circuit): 200mVpp to 20Vpp
(600Ω): 100mVppto10Vpp
Output impedance: 600Ω
Frequency range: 0.1Hz to 20KHz
Pulse signal
Output terminal: ASK mode, synchronization
output
Level: TTL
Pulse width tw: 10μS < tw < 100s
Intervals ts: 10μS < ts < 100s
SWEEP
Sweep range: 1Hz to upper limit
minimum frequency step: 0.4Hz
Sweep time: 10mS to 40S
Trigger mode: internal, external, single
FSK
PSK
ASK
BURST
Pulse breadth, internal: 10μSto100S
Trigger: internal, external, single
Carrier waveform frequency: 1Hz to upper limit
Frequency resolution: 0.4Hz
Carrier waveform: All internal waveforms
