Page #32 background imageLoading...
Page #32 background image
Phase: -360 to 360 degree
Burst pulse: 1 to 65535
Internal
amplitude
modulation
Carrier waveform: All internal waveforms (except
square wave)
Carrier waveform frequency: 1Hz to upper limit
Frequency resolution: 0.4Hz
Modulation waveform: All internal waveforms
Modulation frequency: 100mHz to 20kHz
Modulation frequency stability: 50ppm
Modulation depth: 0%to100%
Input impedance: 100kΩ
External
amplitude
modulation
Modulation depth: Set by the amplitude of the
external modulation signal.
Frequency
modulation
Carrier waveform: all internal waveforms
Carrier waveform frequency: 1Hz to upper limit
Frequency resolution: 0.4Hz
Modulation waveform: All internal waveforms
Modulation frequency: 100mHz to 10KHz
Frequency stability: 50ppm
Frequency deviation range: 1Hz to upper limit
Phase
modulation
Carrier waveform: Sine, square
Carrier waveform frequency: 1Hz to upper limit
Frequency resolution: 0.4Hz
Modulation waveform: internal waveforms
Modulation frequency: 100mHz to 10KHz
Frequency stability: 50ppm
Max. phase offset: 360 degree
Frequency
counter
Tested frequency range: 1Hz to 100MHz
Input signal: >100mV
Ranges 1Hz to 100Khz and 100KHz to 100MHz
29
