NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2015, Pinnacle Products International, Inc. Kerosene Forced Air Heater User’s Manual
®
1 Fuel Tank Assembly
2 Drain Plug
3 Fuel Gauge Assembly
4 Fuel Filter Assembly
5 Fuel Cap
6 Power Cord
7 Power Switch
8 Window Display
9 Thermostat Control Knob
10 Lower Shell
11 Air Line
12 Thermostat Limit Control
13 Combustion Chamber Assembly
14 Photocell Bracket
15 Fuel Line
16 Photocell Assembly
17 Burner Head Assembly
18 Nozzle Kit
19 Spark Plug Kit
20 Motor and Pump Assembly
21 Motor
22 Pump Body
23 Rotor Kit
24 End Pump Cover
25 Filter Kit
26 Lint Filter
27 Output Filter
28 Intake Filter
29 End Filter Cover
30 Plug/Pump Adjustment Kit
31 Nipple
32 Capacitor
33 Fan Assembly
34 Ignitor
35 Right Side Cover
36 Left Side Cover
37 Fan Guard
38 Main PCB Assembly
39 Fuse
40 Clip Nut
41 Upper Shell
42 Bushing Grommet
43 Socket Cover
44 Air Pressure Gauge
45 Cord Bushing
46 Electric Outlet
47 Handle
48 Front Handle
49 Rear Handle
50 Wheel Support Frame
51 Wheel Axle
52 Wheel
53 Wheel Nut
54 Hardware Kit
55 Cord Wrap
56 Motor Supporter
Item Part Number for Models:
No. Description PT-45-KFA PT-70T-KFA PT-75T-KFA PT-125T-KFA PT-175T-KFA PT-215T-KFA
14
Parts List
70-002-0150 70-002-0150 70-002-0150 70-002-0250 70-002-0350 70-002-0350
– – – 70-002-0105 70-002-0105 70-002-0105
70-007-0110 70-007-0115 70-007-0115 70-007-0210 70-007-0210 70-007-0215
70-003-0100 70-003-0100 70-003-0100 70-003-0200 70-003-0200 70-003-0200
70-006-0500 70-006-0500 70-006-0500 70-006-0500 70-006-0500 70-006-0500
70-034-0100 70-034-0205 70-034-0205 70-034-0205 70-034-0205 70-034-0205
70-038-0100 70-038-0100 70-038-0100 70-038-0100 70-038-0100 70-038-0100
– – – 70-040-0100 70-040-0100 70-040-0100
– 70-031-0100 70-031-0100 70-031-0100 70-031-0100 70-031-0100
– – – – – –
70-035-0100 70-035-0200 70-035-0200 70-035-0300 70-035-0400 70-035-0500
70-019-0100 70-019-0100 70-019-0100 70-019-0100 70-019-0100 70-019-0200
70-011-0100 70-011-0200 70-011-0200 70-011-0300 70-011-0400 70-011-0500
70-010-0101 70-010-0101 70-010-0101 70-010-0101 70-010-0101 70-010-0101
70-036-0100 70-036-0200 70-036-0200 70-036-0300 70-036-0400 70-036-0500
70-016-0100 70-016-0100 70-016-0100 70-016-0100 70-016-0100 70-016-0100
70-014-0101 70-014-0101 70-014-0101 70-014-0301 70-014-0401 70-014-0401
70-015-0100 70-015-0200 70-015-0200 70-015-0300 70-015-0400 70-015-0500
70-052-0100 70-052-0100 70-052-0100 70-052-0200 70-052-0200 70-052-0200
70-020-0550 70-020-0550 70-020-0550 70-020-0555 70-020-0560 70-020-0565
70-021-0500 70-021-0500 70-021-0500 70-021-0510 70-021-0520 70-021-0520
70-020-0101 70-020-0101 70-020-0101 70-020-0101 70-020-0101 70-020-0401
70-022-0100 70-022-0100 70-022-0100 70-022-0100 70-022-0100 70-022-0200
70-020-0102 70-020-0102 70-020-0102 70-020-0102 70-020-0102 70-020-0102
70-054-0100 70-054-0100 70-054-0100 70-054-0100 70-054-0100 70-054-0100
70-054-0102 70-054-0102 70-054-0102 70-054-0102 70-054-0102 70-054-0102
70-054-0100 70-054-0100 70-054-0100 70-054-0100 70-054-0100 70-054-0100
70-054-0101 70-054-0101 70-054-0101 70-054-0101 70-054-0101 70-054-0101
70-020-0103 70-020-0103 70-020-0103 70-020-0103 70-020-0103 70-020-0103
70-055-0100 70-055-0100 70-055-0100 70-055-0100 70-055-0100 70-055-0100
70-014-0104 70-014-0104 70-014-0104 70-014-0104 70-014-0104 70-014-0104
70-020-0107 70-020-0107 70-020-0107 70-020-0201 70-020-0201 70-020-0201
70-024-0100 70-024-0200 70-024-0200 70-024-0300 70-024-0400 70-024-0400
70-037-0300 70-037-0300 70-037-0300 70-037-0300 70-037-0300 70-037-0300
– – – – – –
70-009-0120 70-009-0125 70-009-0130 70-009-0130 70-009-0135 70-009-0135
70-016-0700 70-016-0700 70-016-0700 70-016-0200 70-016-0200 70-016-0220
70-027-0100 70-027-0200 70-027-0200 70-027-0300 70-027-0300 70-027-0300
70-027-0101 70-027-0101 70-027-0101 70-027-0101 70-027-0101 70-027-0101
70-001-0105 70-001-0105 70-001-0105 70-001-0105 70-001-0105 70-001-0105
– – – – – –
70-017-0100 70-017-0100 70-017-0100 70-017-0100 70-017-0100 70-017-0100
70-030-0100 70-030-0100 70-030-0100 70-030-0100 70-030-0100 70-030-0100
70-025-0100 70-025-0100 70-025-0100 70-025-0100 70-025-0100 70-025-0100
70-033-0100 70-033-0100 70-033-0100 70-033-0200 70-033-0200 70-033-0200
70-029-0100 70-029-0100 70-029-0100 70-029-0100 70-029-0100 70-029-0100
70-001-0103 70-001-0103 70-001-0103 – – –
– – – 70-042-0100 70-042-0200 70-042-0200
– – – 70-043-0105 70-043-0205 70-043-0205
– – – 70-041-0101 70-041-0201 70-041-0201
– – – 70-041-0115 70-041-0205 70-041-0205
– – – 70-041-1400 70-041-1400 70-041-1400
– – – 70-041-0550 70-041-0550 70-041-0550
70-056-0100 70-056-0100 70-056-0100 70-056-0210 70-056-0210 70-056-0210
70-032-0100 70-032-0100 70-032-0100 70-032-0200 70-032-0200 70-032-0200
70-020-0600 70-020-0600 70-020-0600 70-020-0610 70-020-0610 70-020-0610
