Assembly Instructions
Models: PT-45-KFA / PT-70T-KFA / PT-75T-KFA
What’s In The Box
Figure 3
Figure 4
- Remove the heater and all packaging materials
from the shipping carton
Note: Save the box and packaging materials
for future storage.
Missing Parts? Please Call 800-641-6996 For Assistance
Carry Handle Assembly
1. Align holes in the upper housing with the 2
holes in the handle as shown in Figure 3.
2. Insert screws (13 mm) and tighten firmly.
Cord Wrap Assembly (Optional)
1. Insert tabs into square slots in shell support
and line up screw holes as shown in Figure 4.
2. Insert screws (10 mm) and tighten firmly.
Tools Needed:
- Phillips Head Screw Driver
Cord Wraps (Optional) Carry Handle (1) 10 mm Screws (2) 13 mm Screws (2)
Shown With Optional Cord Wraps and Power Outlet
