NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2015, Pinnacle Products International, Inc. Kerosene Forced Air Heater User’s Manual
®
3
Specications
Features
Model # PT-45-KFA PT-70T-KFA PT-75T-KFA PT-125T-KFA PT-175T-KFA PT-215T-KFA
Rating: Btu/Hr 45,000 70,000 75,000 125,000 175,000 215,000
Fuel Consumption: Gal/Hr .35 .53 .56 .95 1.33 1.63
Fuel Tank Capacity: Gallons 5.0 5.0 5.0 10.0 13.0 13.0
Pump Pressure: psi 3.0 4.0 4.2 5.0 7.5 9.0
Volts: AC/Hz
120VAC / 60Hz 120VAC / 60Hz 120VAC / 60Hz 120VAC / 60Hz 120VAC / 60Hz 120VAC / 60Hz
Amps 1.4 1.5 1.5 2.3 2.7 2.8
Phase
Single Single Single Single Single Single
Specications subject to change without notice.
Hot Air Outlet
Upper Shell
Lower Shell
Fuel Tank
Fan Guard
Optional Pressure Gauge
Fuel Gauge
Fuel Cap
Side Cover
Thermostat Knob
(PT-70T-KFA only)
Lamp
Power Cord
Power/Reset Switch
Handle
Optional
Extension
Cord Wrap
Optional Electric Outlet
(120V 5amp max non fused)
Hot Air Outlet
Lower Shell
Upper Shell
Digital
Temperature
Display
Front Handle
Optional Extension
Cord Wrap
Rear Handle
Fan Guard
Optional Pressure Gauge
Fuel
Gauge
Fuel Cap
Power Cord
Power/Reset Switch
Lamp
Side Cover
Thermostat Knob
Fuel Tank
Drain Plug
Side Cover
Optional Electrical
Outlet (120V 5amp
max non-fused)
Models: PT-45-KFA / PT-70T-KFA / PT-75T-KFA
Models: PT-125T-KFA / PT-175T-KFA / PT-215T-KFA
Figure 1
Figure 2
