Tsunami
®
800 & 8000 Series - Software Management Guide 32
This screen contains the following device information:
·
MAC Address
·
System Name
·
IP Address
·
Uptime
·
System Description: The system description comprises the following information:
— Device Description: For example, MP-820-BSU-100-WD
— Firmware Version: 2.X.Y; For example, version 2.6.2
— Serial Number : For example, SN-12PI06000034
— Bootloader Version: For example, BL - V1.0.4
4. Click Select Adapter, to change adapter settings.
5. From the list, identify and select the MAC address of the device that needs to be initialized, and click Web Config to
log on to the Web Interface.
: If the device does not appear in the Scan List, click Rescan in the Scan List screen. If the device still does not appear
in the list, see
z
. Note that after rebooting the device, it may take up to five minutes for the device to
appear in the Scan List.
3.1.3 Modifying the IP Address of the Device by using ScanTool
To modify the IP address of a device by using ScanTool, select the device from the scan list and click Change. A Change
screen appears as shown in the following screen. The system automatically populates the MAC Address, System Name,
TFTP Server IP Address and Image File Name of the device, which are read-only.
Figure 3-3 Modifying Device’s IP Address (IPv4)
