8 User’s / Programming Guide
Setup Overview
General setup parameters are divided into Keyboard Wedge options
(communication to host through the terminal keyboard), Wand Emu-
lation options (communication between the scanner and the host sys-
tem’s decoder), and Serial Communication options (communications
direct to the host system).
Default options are denoted throughout the manual as follows:
— Keyboard Wedge @
— Wand Emulation #
— Serial Communication *
Wedge Mode Options
Several wedge mode options are available. Consult the Keyboard
Wedge Parameters section for a complete list.
Wand Emulation Options
The available wand emulation options, listed below, are found in the
section Wand Emulation Parameters.
Bar Code Polarity
• Black High
• White High
Transmitted Code Type
• Same Code Wand Emulation
• Converted to Code 39 (full ASCII)
Simulated Scan Rate
• 5 inches per second
• 10 inches per second
• 15 inches per second
• 20 inches per second
• 50 inches per second
• 70 inches per second
