Serial Communication
Reset Default
To program the communication mode for serial asynchronous com-
munication, scan the following label:
CA Select Serial Output
Baud Rate
There are seven standard serial communication baud rates to select
from. Your scanner and the serial host computer must be set to the
same baud rate. Select the correct rate.
DA Baud Rate = 300 Baud
DB Baud Rate = 600 Baud
DC Baud Rate = 1200 Baud
DD Baud Rate = 2400 Baud
DE Baud Rate = 4800 Baud
DF Baud Rate = 9600 Baud *
DG Baud Rate = 19200 Baud
