57
For example:
1. Load Cell, Precision: 1.990 mV/V, Capacity: 10 kg
2. Load Cell, Precision: 1.980 mV/V, Capacity: 10 kg
Precision = (1.990 + 1.980)/2 = 1.985 mV/V
Capacity = 10 + 10 = 20 kg
WARNING: IF THE
 OR  VALUES ARE CHANGED,  AND 
ACTIVITIES SHOULD BE REPEATED.
•  = Zero calibraon page. When in the Zero calibraon page, pay aenon on
that scale is empty and vibraon is zero. While in this page, press the buon
and observe that screen flashes. Once flashing ends, process is completed. Measured
weight value is accepted as zero and saved.
•  = The page where gain calibraon is made. Before making the gain
calibraon, a weight which must be at the value to be measured must be put on the
scale (for example; 10 kg) and pay aenon on that no vibraon exists. Aer
pressing on the key . The weight value put on the scale is entered via the keys
and . When the key is pressed on, the value will be accepted and gain
calibraon will be completed. Then device weight screen will appear. Span value
cannot be lower than %1 of the
 value. Otherwise, device will alarm the error
 . When the scale is not installed any weight, device will alarm the error
. If  value is selected higher than  value, device will alarm the error
. If environment has excessive amount vibraon for a period more than
25 sec, device wil alarm the error
.
* Please check the Error Code's page.
ENT
ENT
ENT
