6. FRONT PANEL DESCRIPTION
MicroVision
Bleed
Feed
Biocide A
Biocide B
DISPLAY
SCREEN
Fig. 8
6.1 Keypad Operation
UP/DOWN - Dual function keys. Used to move the select (highlighted) box and
to increase and decrease values.
O O - Soft keys used for various functions depending on currently
displayed screen. The key’s function appears above the key on the
display.
