Pulsar ULTRA Series User Manual

Page 13
P050 Negative End
The point at which, the negative gain line intersects the 0.0m distance y axis.
This parameter determines the angle at which the rate of near signal amplitude
suppression, (gain attenuation), is applied, over a distance starting at the gain
breakpoint . See the explanation of P43 for details.
Values Min = -999
Max = 999
P051 Margin Enable
This parameter is associated with P52 End Margin.
1 switches the feature on
0 (off) is the default value
Values Min = 0
Max = 1
Default = 80
Default = 0 off

Pulsar ULTRA Series Specifications

General

Power Supply	12-30 V DC
Process Temperature	-40°C to +90°C (-40°F to +194°F)
Output	4-20mA, HART
Protection	IP68
Resolution	1 mm
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
Dimensions	120 x 120 x 150 mm (aluminum), 120 x 120 x 150 mm (stainless steel)
