What to do if Pulsar Imp+i.s. display shows “L0E”?
If your Pulsar Measuring Instruments display shows “L0E”, it indicates that no valid echo is being received, and the unit has entered a fault condition. To resolve this, verify that the material level is within the device's measurement range and ensure the sensor is positioned perpendicular to the material surface.
Why is the material level consistently incorrect by the same amount on my Pulsar Measuring Instruments?
If your Pulsar Measuring Instruments are consistently displaying an incorrect material level by the same amount, verify that the empty level (P105) has been entered correctly.
How to fix incorrect reading on Pulsar Imp+i.s. Measuring Instruments?
If your Pulsar Measuring Instruments are showing an incorrect reading for the current level, measure the actual distance from the transducer face to the surface of the material. Then, enter Program Mode, access the SyS1 menu, go to P21, press ENTER, type in the measured distance, press ENTER, and wait until “Stor” is displayed. Finally, return to Run Mode; the display should now update to the correct reading.
General| Brand | Pulsar |
|---|---|
| Model | Imp+i.s. |
| Category | Measuring Instruments |
| Language | English |
Details requirements for installing the unit in hazardous environments.
Covers ATEX directive requirements and precautions for hazardous areas.
Specifies power supply and barrier requirements for i.s. installations.
Explains voltage drop impact from i.s. safety Zener barriers and cabling.
Lists suitable barrier types and manufacturers for i.s. applications.
Provides advice on optimal placement and mounting of the IMP+ i.s. unit.
Steps to take before switching on the unit for the first time.
Instructions for cleaning and general upkeep of the IMP+ i.s. unit.
Describes the M16 cable entries and moisture protection.
Explains the terminal connections for the 2-wire loop powered IMP+ i.s. unit.
Explains the importance of the manual and its helpful sections.
Overview of the IMP+ i.s. system's development and capabilities.
Describes the ultrasonic technology and operational principles of the IMP+ i.s.
Details the physical, environmental, and performance characteristics of the IMP+ i.s.
Official declaration confirming compliance with EU directives.
Explains how to interact with the IMP+ i.s. unit's controls and display.
Describes the LCD display readings in Run and Program modes.
Details the default operating mode for monitoring level, distance, or space.
Explains how to enter and use Program Mode for setting up the unit.
Details the functions of the four push buttons in Run and Program modes.
Step-by-step guide to entering Program Mode via passcode entry.
Illustrates the menu structure and how to navigate parameters.
Discusses setting parameters to default values before configuration.
Instructions on resetting all parameters to their original factory settings.
Guides on setting up the IMP+ i.s. for specific measurement applications.
Defines and sets the empty level (P105) for distance measurement.
Defines and sets the span (P106) based on empty and full levels.
Configures near (P107) and far (P108) blanking to avoid false readings.
Explains how to configure and use the 4-20 mA output for remote monitoring.
How to set and manage passcodes for accessing Program Mode.
Explains how to enable, disable, and use passcodes for unit security.
Procedure for changing the default passcode from 0000 to 9999.
How to restore all parameters to their original factory settings.
How to view specific unit details like software revision and serial number.
Methods to display the unit's software revision and serial number.
Introduces the section detailing all parameters in the IMP+ i.s.
Parameters related to the application mode, measurement units, and distance settings.
Sets the operating mode: Distance, Level, Space, or Volume.
Selects units for programming and display (metres, cm, mm, feet, inches).
Sets the maximum distance to the empty point, affecting span.
Sets the distance from empty level to maximum material level.
Defines the minimum measurable distance from the transducer face.
Sets the percentage beyond empty level for measurement.
Parameters for calculating and displaying volume based on vessel shape.
Determines the vessel shape for volume conversion calculations.
Input parameters for vessel dimensions required for volume calculation.
Read-only display of the calculated volume based on empty and span levels.
Selects the units for totalized volume (Tons, Litres, Barrels, etc.).
Enters a correction factor, e.g., specific gravity, for volume calculation.
Read-only display of the maximum calculated volume with correction factor.
Parameters for configuring the display units, decimal places, and fail-safe modes.
Determines if readings are in measurement units or percentage of span.
Sets the number of decimal places shown on the display in run mode.
Configures how the display behaves during a fail-safe condition.
Sets the time delay before fail-safe mode is activated.
Parameters for configuring the 4-20 mA output and fail-safe behavior.
Sets the level value at which 4 mA output occurs.
Sets the level value at which 20 mA output occurs.
Trims the low end of the 4-20 mA output for calibration.
Trims the high end of the 4-20 mA output for calibration.
Determines mA output behavior during fail-safe conditions.
Parameters for adjusting measurements based on offset, temperature, and sound velocity.
Adds an offset value to the measured distance.
Selects the source for temperature measurement (internal or fixed).
Sets a fixed temperature value if internal source is not used.
Allows adjustment of sound velocity for different atmospheric conditions.
Adjusts sound velocity for temperature changes in various atmospheres.
Parameters for adjusting display damping to ignore minor fluctuations.
Sets the maximum rate of response to an increase in level.
Sets the maximum rate of response to a decrease in level.
Parameters for unit identification, passcode, and factory reset.
Enables or disables the passcode requirement for Program Mode.
Sets or displays the passcode for accessing Program Mode.
Displays the current firmware revision of the unit.
Displays the unique serial number of the unit.
Resets all parameters to their original factory settings.
Provides diagnostic tests for the display, keys, and mA output.
Tests the display segments and key button functionality.
Tests the mA output by forcing a specified current.
Lists common operational symptoms and their corresponding 'What to Do' actions.
Record of default and entered values for Application menu parameters.
Record of default and entered values for Volume menu parameters.
Record of default and entered values for Display menu parameters.
Record of default and entered values for mA Output menu parameters.
Record of default and entered values for Compensation menu parameters.
Record of default and entered values for Stability menu parameters.
Record of default and entered values for System menu parameters.
