Pulsar ULTRA Series User Manual

Page 21
The number of times the voltage to the wiper motor has to fall below the fail set
point before a wiper fail indication is initiated.
Values Min = 0
Max = 999999
To initiate a wipe from the run mode in order to check the wiper functionality the
F5 hot key should be pressed.
Application Type Auto Parameter Settings
Parameter
SBR
Industrial
Primary
Secondary
Breakpoint in
mm
1.0m
1.5m
1.5m
1.0m
Slope
5
10
10
15
Fill Damping in
mm
200
50
20
20
Empty
Damping in mm
200
100
20
20
Settle Zone
Signal
Suppression
No
Yes
Yes
Yes

Pulsar ULTRA Series Specifications

General

Power Supply	12-30 V DC
Process Temperature	-40°C to +90°C (-40°F to +194°F)
Output	4-20mA, HART
Protection	IP68
Resolution	1 mm
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
Dimensions	120 x 120 x 150 mm (aluminum), 120 x 120 x 150 mm (stainless steel)
