CONNECTIONTERMINATION
Wheneverpossible,usefullplasticencasement.Wedonotrecommendmetalonestoavoidgrounding
leakstoPulse-Eightproducts.TerminatethecablingusingRJ45connectorstothe568Bwiring
standard.(Seediagram)
IMPORTANT:Pleasenotethatlocalbuildingregulationsmayapplytotheinstallationof
cablinginproperties.Itisimportanttocheckbuildingregulationstoguaranteethatyou
areinaccordancewiththelawsofyourterritory.
IRPINASSIGNMENTS
WehighlyrecommendyoupurchaseaPulse-EightMono-StereoOptocableifyouwishtoconvertthis
intoa3.5mmstereojack.However,ifyouchoosetorewiretheIRbudthiswillvoidyourwarrantyonthe
IRaccessory.
A. 5V
B. IRSignal
C. Ground
