Puma 20 - Page 35

Electric diagrams R-net (1)
RNet Drive & Lights
Cable lenghts are not drawn to scale
Lighting
6000038
6000039
6000038
6000039
RNet 2 Puma2040
9002484 (1.5m)
9002482 (2m)
9006331
9006332
PM
JSM
ISM
Lighting
Batteries
1x 100A
9006230
9006228
Motor Motor
RNet Battery & Motor connections (Drive only)
9002484 (1.5m)
Cable lenghts are not drawn to scale
RNet 1 Puma2040
JSM
PM 120A
1x 70A
9006229
PM 120A PM EL (90A)
PM EL (90A)
JSM
Batteries
Motor
Motor
Puma 20/40/60
Spare parts | 35
