Pyle PIPCAMHD46 User Manual

PIPCAMHD46/47 USER MANUAL
44
SPECIFICATIONS
Image Sensor
1/3" Color CMOS Sensor
Display Resolution
1280 x 960 Pixels (1300K Pixels, i.e. 1.3 Megapixel)
Lens
3.5-13.7mm
Mini. Illumination
0.5 Lux
Image Sensor
Viewing Angle
60 Degree
Input
Built-in Microphone/1 channel audio input
Output
1 channel audio output
Audio
Audio Compression
ADPCM
Image Compression
H.264
Image Frame Rate
30fps (VGA),30fps (QVGA)
Resolution
1280 x 960 (VGA), 640 x 368 (VGA), 320 x 208 (QVGA)
Flip Mirror Images
Vertical / Horizontal
Light Frequency
50Hz, 60Hz, Outdoor
Video
Video Parameters
Brightness, Saturation, Contrast, Hue
Ethernet Interface
Build in 10/100Mbps,Auto MDI/MDIX , RJ-45
Supported Protocol
TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP
ARP/RARP NFS RTSP RTP RTCP
Compress rate level
128Kbps～4Mbps
Wireless Standard
IEEE 802.11b/g/n
Data Rate
802.11b: 11Mbps (max.), 802.11g: 54Mbps (max.), 802.11n: 150Mbps (max.)
Communication
Wireless Security
WEP & WPA WPA2 Encryption
Pan/Tilt Angle
Horizontal: 270° & Vertical: 120°
Infrared Light
36 IR LEDs, Night visibility up to 18 meters
Alarm Input
1 Channel on/off Input
Physical
Alarm Output
1 Channel relay Output
Power Supply
DC 12V/2.0A (EU,US,AU adapter or other types optional)
Power
Power Consumption
7 Watts (Max.)
Operate Temper.
0° ~ 55°C (14°F ~ 131°F)
Operating Humidity
20% ~ 85% non-condensing
Storage Temper.
-10°C ~ 60° (14°F ~ 140°F)
Environment
Storage Humidity
0% ~ 90% non-condensing
CPU
2.0GHZ or above (suggested 3.0GHz)
Memory Size
256MB or above (suggested 1.0GHz)
Display Card
64M or above
Supported OS
Microsoft Windows 2000/XP/Vista/7
PC System
Requirements
Browser
IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers
Certification
CE, FCC, RoHS
