Others Warnings
Do not switch on the car radio for long periods of time when the motor is switched
o. This could cause the car battery to discharge and the vehicle can no longer be
started.
INSTALLATION
Installation Procedures
First complete the electrical connections and then check for correctness.
Installation Opening
This unit can be installed in any dashboard Having
an opening as shown the right gure.
Important:
Remove the transport CD deck screws before use.
To Install the Car Radio
Be sure you test all connections rst, and then follow these steps to install this unit.
1. Make sure the ignition is turned o, and then disconnect the cable from the
vehicle battery’s negative (-) terminal.
2. Disconnect the wire harness and the antenna.
3. Lift the left or right top corner of the plastic outer trim ring then pull it out to
remove it.
4. Insert the two bracket keys into the left and right side of the chassis, as shown the
below gure to separate the chassis from the housing.
ww w.PyleUSA.com
4
182 mm
53 mm
Bracket key
Plastic outer trim ring
Bracket key
To Next Page
