cable (Fuse to
DC Isolator)
Current: 100A
Terminal: M8*2
2 pairs (Positive+Negative)
third party
3
Battery power
cable (DC
Isolator to
busbar)
4AWG;
Current: 100A
Terminal: M8*2
2 pairs (Positive+Negative)
Pytes or other
third party
4
Battery power
Cable (Busbar
to DC Isolator)
00AWG;
Current: 200A
Terminal: M8*2
1 pair (Positive+Negative)
Pytes or other
third party
5
Battery power
cable (DC
Isolator to
Inverter)
00AWG;
Current: 200A
Terminal: Amphenol*1, M8*1
1 pair (Positive+Negative)
Pytes or other
third party
6
BMS cable
Pytes or other
third party
Cables delivered with the battery
No.
Cable
Type
Source
1
Battery power Cable
4AWG, max 100A current,
two Amphenol connectors
Delivered with the
product
2
Battery cascading
cable
Classic regular ethernet
cable
Delivered with the
product
3
Ground cable
Single-core outdoor copper
cable
Delivered with the
product
5.2 Electrical Connections of the Battery
Installing battery Ground Cable
Ensure that the PE cable is securely connected. Otherwise, electric shocks may occur.
It is recommended that silica gel or paint be used around the ground terminal after the
PE cable is connected.
