Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
BUS LINE CODEX TRANSCEIVER.
By using the bus line transceiver, the HSC816 has the capability of accepting up to 16 codex transmitters.
Each button could be assigned to any of the keypad functions with encrypted user identification, any keypad
emergency condition or any trigger output.
Each transmitter button is programmed independently of any other remote and is an end user function
The Transceiver also allows for up to 16 wireless zones, including low battery, tamper and supervision
The transmitter code and button functions are taught to the system in end user programming
function level #2 this allows the user to add or delete transmitters when necessary.
Connect using the top bus on the HSC816
Green………Data bus line green wire
Yellow….…..Data bus line yellow wire
Red…………Data bus line red wire (+)
Black……….Data bus line black wire (-)
To Next Page
