Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
31
24 Hour Non-Burglary - 150 and 160
150
24 Hour Non-Burglary Zone
5
2
151
Gas Detected Zone
6
2
152
Refrigeration Zone
7
2
153
Loss Of Heat Zone
8
2
154
Water Leakage Zone
9
2
155
Foil Break Zone
A
2
156
Day Trouble Zone
B
2
157
Low Bottled Gas Level Zone
C
2
158
High Temp Zone
D
2
159
Low Temp Zone
E
2
161
Loss Of Air Flow Zone
F
3
162
Carbon Monoxide Detected Zone
0
3
163
Tank Level Zone
1
3
SUPERVISORY
Fire Supervisory - 200 and 210
200
Fire Supervisory Zone
2
3
201
Low Water Pressure Zone
3
3
202
Low CO2
4
3
203
Gate Valve Sensor Zone
5
3
204
Low Water Level Zone
6
3
205
Pump Activated Zone
7
3
206
Pump Failure Zone
8
3
System Troubles - 300 and 310
300
System Trouble Zone
9
3
301
AC Loss Zone
A
3
302
Low System Battery Zone
B
3
303
RAM Checksum Bad Zone
C
3
304
ROM Checksum Bad Zone
D
3
305
System Reset Zone
E
3
306
Panel Programming Changed Zone
F
3
307
Self- Test Failure Zone
0
4
308
System Shutdown Zone
1
4
309
Battery Test Failure Zone
2
4
310
Ground Fault Zone
3
4
311
Battery Missing/Dead Zone
4
4
312
Power Supply Over Current Zone
5
4
313
Engineer Reset User
6
4
Sounder / Relay Troubles - 320
320
Sounder / Relay Zone
7
4
321
Bell 1 Zone
8
4
322
Bell 2 Zone
9
4
323
Alarm Relay Zone
A
4
324
Trouble Relay Zone
B
4
325
Reversing Relay Zone
C
4
326
Notification Appliance Ckt.# 3 Zone
D
4
327
Notification Appliance Ckt.#4 Zone
E
4
System Peripheral Trouble - 330 and 340
330
System Peripheral Trouble Zone
F
4
331
Polling Loop Open Zone
0
5
332
Polling Loop Short Zone
1
5
333
Expansion Module Failure Zone
2
5
