QD Dynamics Pi HSC816 User Manual

Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
29
Q331
Codex remote16
Button 1
Button 2
Button 3
Button 4
Q332
Codex remote16
Button 5
Button 6
Button 7
Button 8
Q333
Codex remote16
Button 9
Button 10
Button 11
Button 12
Q334
Codex remote16
Button 13
Button 14
TABLE: A
Restricted Ademco point Id table compatible with the QD old software radios
24 Hour Types
Event Type = 1
L3
L4
Description
Event Qualifier
Event Code
Digit 1
Digit 2
Medical
1
100
1
0
Fire
1
110
2
0
Smoke
1
111
3
0
Panic
1
120
4
0
Duress
1
121
5
0
Silent Panic
1
122
6
0
Audible Panic
1
123
7
0
Tamper by zone
1
137
8
0
24 Hour
1
133
9
0
NULL (Disabled)
A
A
Refrigeration
1
152
B
0
Water Leak
1
154
C
0
24 Hour Non-Burglary
1
150
D
0
Pendent Transmitter
1
101
E
0
Gas Detect
1
151
F
0
Burglary Zone Types
Event Type = 0
L3
L4
Description
Event Qualifier
Event Code
Digit 1
Digit 2
Audible Panic
1
123
0
0
Burglary
E= Burg R= Res
130
1
0
Perimeter
1
131
2
0
Interior
1
132
3
0
Silent Instant
1
146
4
0
Entry / Exit
1
134
5
0
Day / Night
1
135
6
0
Outdoor
1
136
7
0
Tamper
1
137
8
0
Silent Panic
1
122
9
0
NULL (Disabled)
A
A
General Alarm
1
140
B
0
Foil Break
1
155
C
0
Day Trouble
1
156
D
0
Sensor Tamper
1
144
E
0
Pendent Transmitter
1
101
F
0
General Types
Description
Event Qualifier
Event Code
Digit 1
Digit 2
System Peripheral Trouble
1
330
0
0
AC
E=Fail R=Restore
301
1
0
Low Battery
1
302
2
0
Test Reports (Auto)
1
602
3
0
Open / Close By User
E=Open R=Close
401
4
0
Auto Arm
3
403
5
0
Cancel on Open
1
406
6
0
Remote Arm
3
407
7
0
Zone Bypass
1
570
8
0
Fire Zone Bypass
1
571
9
0
NULL (Disabled)
A
A
24 Hour Zone Bypass
1
572
B
0
Quick Arm
3
408
C
0
