QD Dynamics Pi HSC816 User Manual

Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
30
Arm Home (Stay)
3
441
D
0
Key Switch
E=Open R=Close
409
E
0
Time / Date Inaccurate
1
626
F
0
Bell Trouble
1
321
0
1
Telco Fault
E=fail R=restore
351
1
1
Battery Test Failure
1
309
2
1
TABLE: B
Full Point ID Table (must only be used with new serial TX firmware. Or with teledialer)
CODE
ALARMS
Program Data
Medical Alarms - 100
L1
L2
No Reporting (Reporting Disabled)
0
0
100
Medical Zone
1
0
101
Personal Emergency Zone
2
0
102
Fail To Report In Zone
3
0
Fire Alarms -110
110
Fire Zone
4
0
111
Smoke Zone
5
0
112
Combustion Zone
6
0
113
Water Flow Zone
7
0
114
Heat Zone
8
0
115
Pull Station Zone
9
0
116
Duct Zone
A
0
117
Flame Zone
B
0
118
Near Alarm Zone
C
0
Panic Alarms - 120
120
Panic Zone
D
0
121
Duress User
E
0
122
Silent Zone
F
0
123
Audible Zone
0
1
124
Duress - Access Granted Zone
1
1
125
Duress - Egress Granted Zone
2
1
Burglar Alarms - 130
130
Burglary Zone
3
1
131
Perimeter Zone
4
1
132
Interior Zone
5
1
133
24 Hour (Safe) Zone
6
1
134
Entry / Exit Zone
7
1
135
Day / Night Zone
8
1
136
Outdoor Zone
9
1
137
Tamper Zone
A
1
138
Near Alarm Zone
B
1
139
Intrusion Verifier Zone
C
1
General Alarm - 140
140
General Alarm Zone
D
1
141
Polling Loop Open Zone
E
1
142
Polling Loop Short Zone
F
1
143
Expansion Module Failure Zone
0
2
144
Sensor Tamper Zone
1
2
145
Expansion Module Tamper Zone
2
2
146
Silent Burglary Zone
3
2
147
Sensor Supervision Failure Zone
4
2
