QD Dynamics Pi HSC816 User Manual

Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
16
QUESTION 1 to 16:
Location 1 = Zone type Location 2 = Reserved
Location 3 = Chime and home types Location 4 = Hardwired / wireless.
Location 1: Zone type
0
Disabled
1
Entry / exit
2
Follower
3
Instant audible
4
Instant silent
5
24-hour audible
6
24-hour silent
7
24-hour panic
8
24-hour panic silent
9
Fire
A
24-hour tamper
B
Keypad buzzer
C
24-hour keypad buzzer
D
Trigger event only
E
Key switch
F
Codex transmitter
Location 2: Reserved
Location 3: Selectable buzzer, chime and home modes (End user programming will change this
location)
Location 4: Hardwire, wireless, tamper and bypass enable
Location 3 Location 4
Value
KP
buzzer
Chime
enable
Home 2
enable
Home 1
enable
Value
Wireless
zone
Hard
wired
Tamper
enable
Bypass
disable
0
0
1


1


2

2

3


3


4

4

5


5


6


6


7



7



8

8

9


9


A


A


B



B



C


C


D



D



E



E



F




F




Note: Tamper selection for hardwired zones requires dual end of line wiring
Tamper selection is required for wireless detectors to enable the detectors Tamper
