QD Dynamics Pi HSC816 User Manual

Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
18
QUESTION 45: Timers
Location 1 = Siren timer Location 2 = Siren delay timer
Location 3 = Tel line fault timer Location 4 = Ac fail (random time of 1 to 16 minutes + Selection)
Siren Duration
Siren Delay
Line fault Timer
AC fail / restore
duration
Value
Delay
Value
Delay
Value
Delay
Value
Delay
0
2 Seconds
0
2 Seconds
0
2 Seconds
0
1 Minute
1
4 Seconds
1
4 Seconds
1
4 Seconds
1
5 Minutes
2
6 Seconds
2
6 Seconds
2
6 Seconds
2
10 Minutes
3
10 Seconds
3
10 Seconds
3
10 Seconds
3
15+ Random
4
20 Seconds
4
20 Seconds
4
20 Seconds
4
20+ Random
5
30 Seconds
5
30 Seconds
5
30 Seconds
5
25+ Random
6
40 Seconds
6
40 Seconds
6
40 Seconds
6
30+ Random
7
50 Seconds
7
50 Seconds
7
50 Seconds
7
35+ Random
8
60 Seconds
8
60 Seconds
8
60 Seconds
8
40+ Random
9
90 Seconds
9
90 Seconds
9
90 Seconds
9
50+ Random
A
120 Seconds
A
120 Seconds
A
120 Seconds
A
60+ Random
B
150 Seconds
B
150 Seconds
B
150 Seconds
B
70+ Random
C
180 Seconds
C
180 Seconds
C
180 Seconds
C
80+ Random
D
210 Seconds
D
210 Seconds
D
210 Seconds
D
90+ Random
E
240 Seconds
E
240 Seconds
E
240 Seconds
E
100+ Random
F
255 Seconds
F
255 Seconds
F
255 Seconds
F
250+ Random
QUESTION 47: Trigger timers (hardwired)
Location 1 = Trigger 1 Location 2 = Trigger 2
Location 3 = Trigger 3 Location 4 = Trigger 4
QUESTION 48: Reserved
QUESTION 49: Trigger timers (triggers on remote expander)
Location 1 = Trigger 9 Location 2 = Trigger 10
Location 3 = Trigger 11 Location 4 = Trigger 12
Value
Delay
0
2 Seconds
1
4 Seconds
2
6 Seconds
3
10 Seconds
4
20 Seconds
5
30 Seconds
6
40 Seconds
7
50 Seconds
8
60 Seconds
9
90 Seconds
A
120 Seconds
B
150 Seconds
C
180 Seconds
D
210 Seconds
E
240 Seconds
F
255 Seconds
QUESTION 50 to 53: Reserved
