Qel M-CONTROLLER II - Page 32

M-Controller II System Operation Manual - 32 -
84350-201-001 Rev C
Holding Register Address Table
Modbus
Name
D
escrip
tion
40001 Relay1 and Relay 2
Statuses
Relay1 status in High 8 bits, Relay 2 status in Low 8 bits
Status Byte Definition:
0: Normal
1: Sensor Alarm
2: Communication Error
3: Offline
4: Sensor Gas type Error
5: Relay/Buzzer/Strobe/Trigger in On Delay process
6: Relay/Buzzer/Strobe in Off Delay process
7: Relay in Latched Status
8: Relay/Buzzer/Strobe/Trigger On
9: Relay/Buzzer/Strobe/Trigger Off
10: Relay/Buzzer/Strobe/Trigger in On Delay process (same as 5)
11: Relay/Buzzer/Strobe in Off Delay process (same as 6)
12: No Sensor is assigned to Relay/Buzzer/Strobe/Trigger
13: Buzzer or Buzzer Style Relay is hushed
14: Sensor Fault
15 or 22: Override ON
17 or 23: Override OFF
128: Disabled
40002 Relay3 and Relay4
S
tatuses
Relay3 status in High 8 bits, Relay 4 status in Low 8 bits
Sta
tus Byte Definition
see
40001
40003
to
40049
Relay5 to Relay98
Statuses
Relay5, 7, 9 … status in High 8 bits, Relay6, 8, 10 … status in
Low 8 bits
Status Byte Definit
ion see 40001
40050 Relay99 Status Relay99 status in High 8 bits, Low 8 bits is no use
Status Byte Definit
ion
see 40001
40051 Analog Output CH1
and CH2 Statuses
& mA reading
A-Out CH1 in High 8 bits, A-Out CH2 in Low 8 bits
Byte Definition:
0: Disabled Channel
1 – 255: Analog Output Current Value (mA) X 10
Example:
If (Byte) = 200, the Analog Output value is 20.0 mA.
If (Byte) = 41, the Analog Output value is 4.1 mA.
I
f (Byte) =
0, the Analog
Output
is disabled.
40052
to
40054
Analog Output CH3
to CH8 Statuses &
mA re
ading
A-Out CH3, 5, 7 in High 8 bits, A-Out CH4, 6, 8 in Low 8 bits
Byte Definition see 40051
40055 Buzzer1 and
Buzzer2 Sta
tuse
s
Buzzer1 status in High 8 bits, Buzzer2 status in Low 8 bits
Status Byte Def
inition see 40001
40056 Buzzer3 and Strobe
Statuses
Buzzer3 status in High 8 bits, Strobe status in Low 8 bits
Status Byte Definition see 40001
