M-Controller II System Operation Manual - 33 -
84350-201-001 Rev C
40057 Trigger1 and
Trigger1 status in High 8 bits, Trigger2 status in Low 8 bits
Byte Definition see 40001
40058 Trigger3 Status Trigger3 status in High 8 bits, Low 8 bits is no use
40059 Digital Sensor 0-7
Relay Statuses
Usually, Each Digital Sensor has two Relays onboard:
Relay High (H) and Relay Low (L)
bit(1): ON, bit(0): OFF
b15…b8= Sensor 3H,3L,2H,2L,1H,1L,0H,0L
40060 Digital Sensor 8-15
B15…b8= Sensor 11H,11L,10H,10L,9H,9L,8H,8L
40061 Digital Sensor 16-
B15…b8= Sensor 19H,19L,18H,18L,17H,17L,16H,16L)
40062 Digital Sensor 24-
B15…b8= Sensor 27H,27L,26H,26L,25H,25L,24H,24L
40063 Digital Sensor 0
and Sensor 1
Statuses
Sensor 0 in High 8 bits, Sensor 1 in Low 8 bits
Byte Status Definition:
b7, b3 … b0 is Sensor Status, Status Definition see 40001,
b6, b5, b4 is Decimal Position for its Reading in 40083
example:
b6, b5, b4 = 000, The actual reading is Reading in 40083
b6, b5, b4 = 001, The actual reading is Reading / 10
b6, b5, b4 = 010, The actual reading is Reading / 100
b6, b5, b4 = 011, The actual reading is Reading / 1000
40064
to
Digital Sensor 2 –
31 Statuses
Sensor 2, 4, 6 … in High 8 bits, Sensor 3, 5, 7 … in Low 8 bits
Byte Status Definition see 40063
40079 Analog Input CH1
A-In CH1 in High 8 bits, A-In CH2 in Low 8 bits
40080
to
Analog Input CH3 -
8 Statuses
A-In CH3, 5, 7 in High 8 bits, A-In CH4, 6, 8 in Low 8 bits
Byte Status Definition see 40063
40083
Digital Sensor 0
Gas Reading
The Gas Reading is 16 bits signed integer.
The Actual Reading of the sensor should be divided by its
Decimal Position, see 40063
40084
to
Digital Sensor1-31
Gas Reading
Same as Definition in 40083
40115 Analog Input CH1
Reading without
The Reading is 16 bits signed integer.
The Actual Reading of the Analog Input should be divided by its
40116
to
Analog Input CH2-
8 Reading without
Same as Definition in 40115
