M-Controller II System Operation Manual - 34 -
84350-201-001 Rev C
40123 M-Controller Self
Diagnostics Report
Fault Flag Reg.
b0 = 1, no analog output daughter board plug in
b0 = 0, normal
b1 = 1, polling remote relay fault
b1 = 0, normal
b2 = 1, polling remote sensors fault
b2 = 0, normal
b3 = 1, remote sensor has fault
b3 = 0, normal
b4 = 1, no sensor assigned to an analog output
b4 = 0, normal
b5 = 1, no sensor assigned to a buzzer or a trigger
b5 = 0, normal
b6 = 1, no sensor assigned to the strobe
b6 = 0, normal
b7 = 1, no sensor assigned to relays
b7 = 0, normal
b8 … b15 reserved
#17(11H) Report Slave ID
Function in M-Controller:
Return a description of the type of controller present at the slave address with its
specification.
Broadcast is not supported.
Query:
Slave Addr.: xxH
Function code: 11H
CRC check: xxxxH
Response:
Slave addr.: xxH
Function code: 11H
