QNAP TL-D800C User Manual

4. Basic Operations
This chapter describes basic operations of the JBOD enclosure.
LEDs
LEDs indicate system status and related information when the JBOD enclosure is powered on. The following
LED information applies only when the drive is correctly installed and when the JBOD enclosure is
connected.
For details on the location of the LEDs, see Components.
LED Status Description
System Status Green The JBOD enclosure is ready.
Red • The system fan is not functioning.
• The system temperature is over 65°C.
Link Green The JBOD enclosure is connected to a host device.
Off The JBOD enclosure is not connected to a host device.
Fan Red The system fan is not functioning.
Drive Green • The JBOD enclosure is powered on.
• The drive can be accessed.
Red A drive read/write error occured.
Note
The drive LEDs only function when connected to a NAS or computer running QTS, QTS
hero, or QNAP JBOD Manager.
Audio Alert
Note
The audio alert can be toggled on and off by using the audio alert switch on the rear panel
of the JBOD enclosure.
For details, see Rear Panel.
Duration Frequency Description
Short beep (0.5 seconds) 1 • The link to the JBOD enclosure is up.
• The link to the JBOD enclosure is down.
TL-D800C User Guide
Basic Operations 21

QNAP TL-D800C Specifications

General

Hot-swap	Yes
Storage drive size	2.5/3.5 \
Total installed storage capacity	0 TB
Number of storage drives supported	8
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Noise level	26.2 dB
Country of origin	Taiwan
Data transfer rate	6 Gbit/s
Fan diameter	120 mm
Product type	HDD/SSD enclosure
Product color	Black, Grey
LED indicators	Fan fail, HDD, Link
Number of fans	2 fan(s)
USB version	3.2 Gen 2 (3.1 Gen 2)
USB connector type	USB Type-C
USB ports quantity	1
USB connector gender	Female
Cables included	USB Type-C to USB Type-A
Number of keys included	2 pc(s)
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	281.4 mm
Width	329.3 mm
Height	188.2 mm
Weight	6180 g
Package weight	7540 g
