QNAP TR-002 User Manual

4. RAID Configuration
This section provides information on configuring RAID settings.
Important
The following situations will interrupt the connection to the RAID enclosure, causing data
being written to the drives to be lost.
• Creating or deleting a RAID group while another RAID group or disk is in use
• RAID group failure (excluding degraded mode), or adding or removing a RAID group
while another RAID group is in use
• Inserting or removing a drive when the RAID enclosure is in Individual mode
• Pressing and holding the Set button for three or more seconds, until the RAID
enclosure beeps
Supported RAID Types
QNAP external RAID enclosures support several RAID types.
Important
• When disks with different capacities are combined in one RAID group, all disks
function according to the capacity of the smallest disk. For example, if a RAID group
contains five 2 TB disks and one 1 TB disk, the total capacity will be 6 TB.
• You can only use one disk type (HDD or SSD) in a RAID group. Combining different
types of disk in one RAID group is not supported.
• QNAP recommends creating separate RAID groups for each capacity and type of disk.
Note
The RAID enclosure does not support capacity expansion or RAID-level migration.
RAID Type Number of
Disks
Description Compatibility
JBOD (Just a
Bunch of Disks)
2 or more • JBOD combines disks together in a linear
fashion. The system writes data to a disk
until it is full, and then writes to the next
disk.
• JBOD allows all of the disks capacity to
be used, but does not provide any disk
failure protection or performance
benefits.
• Unless you have a specific reason to use
JBOD, use RAID 0 instead.
• TR-002
• TR-004
QNAP External RAID Enclosure User Guide
RAID Configuration 24

QNAP TR-002 Specifications

General

Hot-swap	Yes
RAID levels	0, 1, JBOD
Storage drive size	2.5/3.5 \
Number of storage drives supported	2
Supported storage drive interfaces	Serial ATA II, Serial ATA III
USB version	3.2 Gen 2 (3.1 Gen 2)
USB connector type	USB Type-C
USB ports quantity	1
Fan diameter	70 mm
Product type	HDD/SSD enclosure
Product color	Black
LED indicators	HDD, SSD, Status, USB
Number of fans	1 fan(s)
Country of origin	Taiwan
Data transfer rate	6 Gbit/s
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Power source type	DC
AC adapter input voltage	100 - 240 V
AC adapter output voltage	12 V
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	AC, USB Type-C
Number of keys included	2 pc(s)
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	219 mm
Width	102 mm
Height	168.5 mm
Weight	1370 g
