QNAP TR-002 User Manual

2. Power on the RAID enclosures.
3. Verify that the RAID enclosures are recognized by the computer.
a. Go to your computer's disk management utility or open QNAP External RAID Manager in
Windows or macOS.
b. Verify that the RAID enclosures are listed.
Attaching the USB Cable Clip
Important
The USB cable clip keeps the cable near the enclosure to avoid potential damage to the
cable or any nearby components.
The clip is not intended to be removed after attaching it to the RAID enclosure.
1. Insert the cable clip into the cable clip slot.
QNAP External RAID Enclosure User Guide
Hardware Installation 20

QNAP TR-002 Specifications

General

Hot-swap	Yes
RAID levels	0, 1, JBOD
Storage drive size	2.5/3.5 \
Number of storage drives supported	2
Supported storage drive interfaces	Serial ATA II, Serial ATA III
USB version	3.2 Gen 2 (3.1 Gen 2)
USB connector type	USB Type-C
USB ports quantity	1
Fan diameter	70 mm
Product type	HDD/SSD enclosure
Product color	Black
LED indicators	HDD, SSD, Status, USB
Number of fans	1 fan(s)
Country of origin	Taiwan
Data transfer rate	6 Gbit/s
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Power source type	DC
AC adapter input voltage	100 - 240 V
AC adapter output voltage	12 V
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	AC, USB Type-C
Number of keys included	2 pc(s)
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	219 mm
Width	102 mm
Height	168.5 mm
Weight	1370 g
