Warning
• Do not touch the components, particularly the metal connectors.
• Do not bend the module.
9. Install a new module.
a. Align the notch with the ridge in the slot.
b. Insert the module.
c. Verify that the metal connectors are fully inserted.
d. Carefully press down on the module until the retention clips lock the module into place.
TS-251B User Guide
Installation and Configuration 30
