QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 117 197
Sensor Test
Shows actual dBm signal strength of each sensor and graphs sensor events
against the ambient noise floor of the environment. Also displays the traditional
packet count method.
The Advanced Sensor Test
shows a summary page of
each sensor paired to the
panel along with the average
dBm level , the last event’s
dBm level and how many
packets were received from
the sensor.
Select the graph icon to the
right of each sensor to view
an individual sensor’s
graphed signal strength in
real time.
Refer to page 99 for the sensor packet results table.
NOTE: For UL/cUL , perform a
placement test first for all wireless
initiating devices. The acceptable result
shall be “Good".
