SECURITY SENSORS
1. Select “Auto Learn Sensor
2. Open/Close or Tamper a sensor to enroll. For PowerG contacts, hold the “enroll” button until
the yellow LED flashes.
3. Panel will chime and display the sensor’s DL code. Select OK to confirm.
4. Configure Partition Name, Sensor Type, Sensor Group, Sensor Name, Chime Type and Voice
Prompts with the smart filtering drop down lists.
5. Select “Add New” to complete and move to the next sensor.
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 56 197
NOTE:
When enrolling an “S-Line” sensor, the panel will auto detect that its encrypted and change the
“Source” field to S-Line.
When enrolling a sensor of a different frequency (345MHz, 433MHz, PowerG) the Source field
will change to accommodate the incoming signal type.
When a sensor with the frequency 345 is used, you will be given an additional field to specify
the Loop #.
AUTO LEARN SENSOR
Note: SRF433 is not for EN Grade 2 Installations. SRF319 and
SRF345 are not for UKCA or CE/EN Grade 2 Installations
