P
ANEL O
VERVIEW
EXTERIOR BACK
F
or EN Grade 2
applications, these
mounting holes
shall be used
Single, double or
triple gang box
compatible
QOLSYS CONFIDENTIAL AND PROPRIET
ARY
PA
G
E
OF
6
197
Locking Screw w
/
Reten
tion Spring
F
or UL2610 and EN Grade
2 applications this screw
shall be used for tamper
protection against
mounting remov
al
RF antenna
routing hole
5
7
