QSC CX-Q Series User Manual

23
TD-001586-01-B
Model: CX-Q 8K4 / CX-Qn 8K4
120 VAC Mains 230 VAC Mains Thermal Dissipation
Output Level Load
100 VAC
Current
AC Current
(Amps)
Losses
(Watts)
AC Current
(Amps)
Losses
(Watts)
BTU/h kcal/hr
Standby
0.8 0.7 79 0.5 83 270 68
Mute All
0.9 0.8 36 0.6 42 123 31
Idle
1.9 1.6 173 0.9 166 590 149
1/8 Rated
Power (Pink
Noise)
100 V /Channel
10.4 8.7 370 4.6 340 1263 318
70 V / Channel
10.6 8.9 382 4.8 360 1304 329
8  / Channel
10.4 8.7 370 4.6 340 1263 318
4  / Channel
10.6 8.9 382 4.8 360 1304 329
2  / Channel
11.6 9.7 472 5.3 452 1611 406
1/3 Rated
Power (1kHz
Sine Wave)
100 V / Channel
21.6 18 533 9.2 453 1819 458
70 V / Channel
22.9 19.1 623 9.7 553 2126 536
8  / Channel
21.6 18.9 533 9.2 453 1819 458
4  / Channel
22.9 19.1 623 9.7 553 2126 536
2  / Channel
24.8 20.7 828 10.5 738 2826 712
Model: CX-Q 4K8 / CX-Qn 4K8
120 VAC Mains 230 VAC Mains Thermal Dissipation
Output Level Load
100 VAC
Current
AC Current
(Amps)
Losses
(Watts)
AC Current
(Amps)
Losses
(Watts)
BTU/h kcal/h
Standby
1.0 0.8 43.9 0.5 42 150 38
Mute All
1.1 0.9 44.9 0.7 49 153 39
Idle
1.9 1.6 182.0 0.9 184 621 157
1/8 Rated
Power (Pink
Noise)
100 V / Channel
4.8 3.98 450 2.1 423 512 129
70 V / Channel
5.0 4.2 472 2.2 438 587 148
8  / Channel
5.4 4.5 455 2.2 421 529 133
4  / Channel
6.2 5.2 536 2.5 495 805 203
2  / Channel
7.4 6.2 654 3.2 553 1208 304
1/3 Rated
Power (1kHz
Sine Wave)
100 V / Channel
10.9 9.1 1044 4.5 988 833 210
70 V / Channel
11.6 9.7 1116 4.8 1047 1079 272
8  / Channel
11.5 9.6 1047 4.5 995 843 212
4  / Channel
12.6 10.5 1223 5.0 1059 1444 364
2  / Channel
15.7 13.1 1523 6.0 1330 2468 622

QSC CX-Q Series Specifications

General

Dante	Yes
THD+N	<0.05%
DSP	Yes
Weight	Varies by model
Power Output	Varies by model
Frequency Response	20Hz - 20kHz (+0/-0.5dB)
Power per channel (8 ohms)	Varies by model
Power per channel (4 ohms)	Varies by model
Power per channel (2 ohms)	Varies by model
Bridged Mode	Yes
Height	2U
Protection	Thermal, short circuit, DC, overload
