PL3 Series Service Manual 105
TD-000274-00 Rev. A
RE-053602-30 536, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 6 R22, R146, R302, R361, R374, R377
RE-093101-30 931, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R379
RE-110006-30 1.00K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 11 R1, R7, R42, R117, R118, R128, R165, R232, R250, R252, R369
RE-115002-30 1.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 16 R23, R32, R34, R35, R39, R41, R101, R109, R147, R154, R157, R158, R162,
R164, R270, R273
RE-116002-00 1.6K, 5 PCNT, 2W, METAL OXIDE FP, , 2 R257, R378
RE-120002-30 2.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R48, R171
RE-122103-30 2.21K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 16 R47, R72, R75, R84, R170, R195, R198, R207, R240, R264, R265, R267,
R306, R307, R347, R348
RE-130102-30 3.01K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R79, R202, R290, R293
RE-134803-30 3.48K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 1 R370
RE-136502-30 3.65K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R297–R300
RE-145302-30 4.53K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R11, R137
RE-147502-30 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 27 R3, R4, R10, R17, R40, R55, R56, R59, R62–R64, R125, R126, R131, R138,
R163, R178, R179, R182, R185–R187, R282, R287, R327, R330, R362
RE-151002-00 5.1K, 5 PCNT, 2W, METAL OXIDE FP, , 5 R96, R105, R219, R228, R251
RE-159002-30 5.90K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 15 R8, R9, R12, R13, R29, R78, R83, R129, R130, R135, R136, R152, R201,
R206, R281
RE-175002-30 7.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 6 R15, R38, R120, R132, R140, R161
RE-178701-30 7.87K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R360
RE-190902-30 9.09K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R127, R258, R266, R272
RE-210003-30 10.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R253, R295, R336, R338, R363, R366, R375, R376
RE-211303-30 11.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R122
RE-212702-30 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 19 R14, R19, R36, R46, R65, R104, R106, R133, R134, R142, R159, R169, R188,
R227, R241, R245, R259, R329, R337
RE-215002-30 15.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 6 R25, R45, R148, R168, R262, R365
RE-216501-CM 16.5K, 1 PCNT, 1/2W, METAL FILM, , 2 R31, R153
RE-220002-30 20.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 10 R18, R141, R229, R242, R244, R271, R291, R294, R331, R346
RE-224901-30 24.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R16, R139, R325
RE-230002-10 30K, 5 PCNT, 2W, METAL OXIDE FP, MINI, 2 R351, R352
RE-230102-30 30.1K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 4 R49, R50, R172, R173
RE-239202-30 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 13 R20, R60, R61, R76, R77, R143, R183, R184, R199, R200, R243, R261, R323
RE-247503-30 47.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 5 R2, R26, R43, R149, R343
RE-269801-30 69.8K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 4 R283–R286
RE-310002-30 100K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 5 R33, R119, R156, R224, R332
RE-310003-30 100K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 12 R51, R53, R73, R74, R174, R176, R196, R197, R268, R288, R344, R345
RE-315002-30 150K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 12 R52, R54, R57, R58, R175, R177, R180, R181, R333, R335, R341, R342
RE-339201-30 392K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 9 R24, R66, R69, R145, R189, R192, R260, R263, R340
RE-339202-30 392K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 4 R321, R322, R326, R328
RE-375005-BM 750K, 5 PCNT, 1/2W, METAL FILM, , 2 R339, R371
RE-410001-30 1.0M, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 2 R289, R292
SC-063100-PP PHILLIPS, PANHEAD, #6-20, 0.625" L, ZINC, TYPE AB, CR111 20
SC-081101-SP PHILLIPS, PANHEAD SERATED BASE, #8-18, 0.625" L, BLACK WAXED, TYPE AB, CR111 8
SW-000104-00 RELAY, SPDT, 24VDC COIL, 20A, 125VAC, T90 STYLE (FOR PLC MODELS) 1K1
WC-0.5018-JW JUMPER, TEFLON INSULATION, 18 AWG SOLID, 1 CONDUCTOR, , 0.5" L, 1 W120
WC-000002-10 JUMPER, BARE, 22 AWG SOLID, 1 CONDUCTOR, , VARIABLE LENGTH, AUTO INSERTABLE 2 W1, W2
WC-000113-10 JUMPER, 0.8" TEFLON INSULATION, 22 AWG, 1 CONDUCTOR, , 0.9" L, AUTO INSERTABLE 1 R280
WC-000115-00 WIRE ASSY, AC SWITCH, 16 AWG, 1 CONDUCTOR, PLC, 14" L, BLACK 1 W7 TO SWITCH
WC-000115-01 WIRE ASSY, AC SWITCH, 16 AWG, 1 CONDUCTOR, PLC, 7" L, RED 1 W6 TO SWITCH
WC-000117-04 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 10.50" L, BLACK 1 W12 W12A-B
WC-000117-05 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 9.50" L, WHITE 1 W9 W9A-B
WC-000117-06 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 11.00" L, GREY 1 W11 W11A-B
WC-000117-07 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 9.50" L, BLACK 1 W10 W10A-B
WC-000118-00 WIRE ASSY, , 16 AWG, 1 CONDUCTOR, PLC, 12.5" L, BLACK 1 W5 W5A-B
WC-000118-01 WIRE ASSY, , 16 AWG, 1 CONDUCTOR, PLC, 10.5" L, RED 1 W8 W8A-B
XF-000005-00 BEAD, 100MHZ, 271 OHM, 6 L7–L12
XF-000023-00 INDUCTOR, COMMON MODE, , 2MH, , , 2 L3, L4
XF-000061-00 INDUCTOR, 2 COUPLED WINDINGS, TOROID, 1.9UH, PL/DCA/CX, 230V, 1L6
XF-000064-00 TRANSFORMER, HOUSEKEEPING, , , , PLC, , 1T1
XF-000066-00 INDUCTOR, ZOBEL CURRENT SENSE, , 2UH, PLC, , 2 L1, L2
XF-000185-00 TRANSFORMER, SWITCHING, 115KHZ, E55, 1500W, DCA1222, 100V, 1T2
PCB Assembly PL325 (100V) continued
QSC Part # Description Qty. Reference Comments
