QSC PowerLight3 Series - Chassis Assembly PL380 (100 V) (QSC Part # WP-038000-01)

To Next Page

To Previous Page

PL3 Series Service Manual 125

TD-000274-00 Rev. A

LB-000409-00 AGENCY, 68FA LISTING, HORIZONTAL, , UL/CUL 1

LB-000439-00 LABEL, WIRE CLASS 2 AND 3, , , 1

LB-000652-00 PRODUCT, FACEPLATE, , PL3, 1

LB-000655-00 PRODUCT, FACEPLATE, , PL380, 1

LB-000673-50 LABEL, CHINA ROHS, 50 YEARS, , SMALL 1

NW-000021-03 FLAT WASHER, 1.14", , STEEL, BLACK ZINC 1

NW-000115-00 STEEL WASHER, 0.437" I.D., 0.628 O.D., STEEL 5702, ZINC PLATED CR3 1

NW-060010-IT LOCK WASHER, #6, INTERNAL TOOTH, , CR111 4

PL-000054-00 KNOB, , PLX, POLYPROPYLENE/SANTOPRENE, BLACK, 2

PL-000066-00 CLIP, CHRISTMAS TREE, , NYLON, BLACK, 2

PL-000095-00 FAN INTERFACE, , PLX 2RU, POLYPROPYLENE, BLACK, 1

PL-000514-00 INSULATOR, FAN DUCT, PL380, FISH PAPER, , 1

RD-000003-XX LABEL, SERIAL NUMBER, PLX/DCA/PL/PL2A/CM16A/PL/DCM 0

SC-025000-PP PHILLIPS, PANHEAD, M2.5, 6MM, BLACK, THREAD FORMING, CR111 8

SC-040041-PP PHILLIPS, PANHEAD, #4-40, 0.25" L, BLACK, CR111 4

SC-060042-PP PHILLIPS, PANHEAD SEMS INTERNAL TOOTH, #6-32, 0.25" L, BLK, ZINC, CR111 2

SC-060060-PS PHILLIPS, SEMS EXTERNAL TOOTH, #6-32, 0.375" L, ZINC, CR111 10

SC-080122-HC HEX, CAP, #8-32, 0.75" L, BLACK, CR111 2

SC-080127-PS PHILLIPS, SEMS EXTERNAL TOOTH, #8-32, 0.75" L, ZINC, CR111 2

SC-082051-PL PHILLIPS, PANHEAD SERATED BASE, #8, 0.313" L, BLACK, CR111 14

SW-000037-00 AC SWITCH, DPST, 20A, 125VAC, 1

SW-000158-00 CIRCUIT BREAKER, THERMAL, 30A, PL380 120V/100V 1

WC-000016-03 RIBBON CABLE ASSY, , 28 AWG, 16 CONDUCTOR, PL 2RU, 15" L, 1 J7A TO J7B

WC-000238-00 RIBBON CABLE ASSY, , 28 AWG, 26 CONDUCTOR, , 7" L, AMP CORP ONLY 1

WC-000346-00 WIRE ASSY, AC FILTER TO MAIN PCB, 12 AWG, 2 CONDUCTOR, PL380, 10.50" L, BLACK/RED 1 (BLACK: J15 TO J22),

(RED: J19 TO J20)

WC-000351-00 AC CORD ASSY, 25 AMP 125V, 12 AWG, 3 CONDUCTOR, PL380, 65" L, 1

WC-000358-00 WIRE ASSY, CIRCUIT BREAKER, 12AWG, 1 CONDUCTOR, PL380, 6" L, BLACK 1

WP-000057-00 FAN ASSY, , PLC, , 1

Chassis Assembly PL380 (100V) (QSC part # WP-038000-01)

QSC Part # Description Qty. Reference Comments

CH-000118-00 RACK EAR, FRONT, , CX902, 2

CH-000496-00 CHASSIS, MAIN, , PL380, 1

CH-000582-00 SHIELD, LINE FILTER, , PL380, 1

CH-000696-00 BRACKET, STOP RING, AC, PL380, 1

HW-040001-00 BRACKET, ANGLE, #4-40, 0.375" L, ZINC PLATED STEEL, 2

HW-060090-SO STANDOFF, 0.250" HEX, #6-32, 0.563" L, ALUMINUM, FEMALE 2

LB-000077-00 WARNING, HIGH ENERGY, , PL 3RU, 1
