PCB Assembly PL325 (230V) (QSC part # WP-032501-02)
QSC Part # Description Qty. Reference Comments
CA-010002-30 10PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 2 C14, C49
CA-015002-10 15PF, 10 PCNT, 500V, CERAMIC SL, DISC, 2 C16, C50
CA-047002-30 47PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 8 C29, C30, C64, C65, C99, C100, C187, C193
CA-110001-10 100PF, 5 PCNT, 500V, MICA, DIPPED, 1 C147
CA-110002-30 100PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 8 C5, C6, C9, C18, C40, C41, C43, C53
CA-133001-10 330PF, 5 PCNT, 500V, MICA, DIPPED, 2 C145, C146
CA-147003-30 470PF, 5 PCNT, 50V, CERAMIC NPO, 1206, 11 C4, C17, C26, C52, C61, C119, C148, C181, C182, C186, C188
CA-168003-30 680PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 2 C25, C60
CA-210005-30 0.001UF, 5 PCNT, 50V, CERAMIC NPO, 1206, 9 C75, C81, C85, C93, C94, C95, C96, C120, C124
CA-222001-00 0.0022UF, 20 PCNT, 125VAC, CERAMIC Y5U, DISC, YCAP 2 C122, C127
CA-227001-30 0.0027UF, 10 PCNT, 100V, CERAMIC X7R, 0805, 11 C20, C23, C24, C55, C58, C59, C68, C98, C108, C109, C128
CA-233001-10 0.0033UF, 10 PCNT, 100V, FILM, DIPPED, 1 C113
CA-233002-00 0.0033UF, 20 PCNT, 125VAC, CERAMIC, DISC, YCAP 2 C115, C118
CA-322001-10 0.022UF, 10 PCNT, 100V, FILM, DIPPED, 2 C27, C62
CA-410001-00 0.1UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP 1 C126
CA-410002-10 0.1UF, 5 PCNT, 100V, FILM, DIPPED, 4 C8, C12, C44, C47
CA-410003-10 0.1UF, 10 PCNT, 250V, FILM, DIPPED, 13 C28, C34, C35, C63, C69, C70, C84, C87, C90, C129, C134, C156, C157
CA-410006-30 0.1UF, 10 PCNT, 50V, CERAMIC X7R, 1206, 19 C19, C54, C88, C116, C125, C135, C155, C162, C163, C177–C180, C183,
C185, C189–C191, C194
CA-410011-00 0.1UF, 10 PCNT, 400V, FILM, DIPPED, 2 C107, C123
CA-422001-10 0.22UF, 5 PCNT, 50V, FILM, DIPPED, LOW PROFILE 2 C10, C45
CA-422004-30 0.22UF, 10 PCNT, 50V, CERAMIC X7R, 1206, 2 C121, C39
CA-447001-00 0.47UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP 1 C117
CA-447003-00 0.47UF, 10 PCNT, 400V, FILM, WRAPPED, PULSE 1 C144
CA-510003-10 1.0UF, 20 PCNT, 50V, ELECTROLYTIC, , 1 C80
CA-510005-30 1.0UF, 20 PCNT, 50V, ELECTROLYTIC, SMT, 2 C13, C48
CA-510006-00 1.0UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP 2 C110, C112
CA-610002-10 10UF, 20 PCNT, 35V, ELECTROLYTIC, , 7 C3, C31, C38, C66, C86, C114, C192
CA-610006-30 10UF, 20 PCNT, 16V, ELECTROLYTIC, SMT, 1 C184
CA-647001-10 47UF, 10 PCNT, 10V, ELECTROLYTIC, , NON-POLAR 11 C7, C11, C42, C46, C71, C91, C92, C102, C104–C106
CA-647002-10 47UF, 20 PCNT, 50V, ELECTROLYTIC, , LOW PROFILE 5 C21, C22, C56, C57, C89
CA-710002-10 100UF, 20 PCNT, 25V, ELECTROLYTIC, , 11 C15, C32, C33, C51, C67, C72, C78, C79, C139, C142, C143
CA-710004-10 100UF, 20 PCNT, 25V, ELECTROLYTIC, , LOW ESR 3 C138, C149, C150
CA-747001-10 470UF, 20 PCNT, 16V, ELECTROLYTIC, , 7 C73, C74, C76, C77, C82, C83, C131
CA-810003-00 1000UF, 20 PCNT, 90V, ELECTROLYTIC, , 10 C152, C153, C159, C160, C165, C166, C169, C170, C173, C174
CA-810004-00 1000UF, 20 PCNT, 55V, ELECTROLYTIC, , 10 C151, C154, C158, C161, C164, C167, C168, C171, C172, C175
CA-822200-AE 2200UF, 20 PCNT, 200V, ELECTROLYTIC, , 6 C132, C133, C136, C137, C140, C141
CH-000102-00 HEAT SINK, AUDIO, , PLX3002, 4
CH-000103-00 CLAMP, TO-3PL, 22 GA, PLX3002, 9
CH-000104-00 HEAT SINK, PS, , PLX3002, 2
CH-000114-00 CLAMP, DIODE, 2 FINGER, PLX3002, 4
CO-000009-ZT ZTAB, 0.025" TAB, 1 POS, MALE, AUTO INSERTABLE 3 J19, J20, J21
CO-000036-CO JACK, SPEAKON, 4 POS, FEMALE, 2 J7, J8
CO-000155-00 HEADER, 0.1" CENTERS, 2 POS (1X2), MALE, RAMP LOCK 1 J13
CO-000193-00 HEADER, 0.1" CENTERS, 20 POS (2X10), MALE, BOX 1 J5A
CO-000194-00 HEADER, 0.1" CENTERS, 20 POS (2X10), MALE, LATCHING BOX 3 J14A, J3B, J5B
CO-000196-00 HEADER, 0.1" CENTERS, 3 POS (1X3), MALE, RAMP LOCK 1 J11
HW-000001-FC FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 3AG 2 REF: F1
IC-000024-00 CONTROLLER, PWM, SG3525AN, , 1 U19
IC-000046-30 OPAMP, DUAL, TLO72, SMT, 2 U11, U12
IC-000047-30 COMPARATOR, DUAL, LM393, SMT, 1 U10
IC-000048-30 OPAMP, DUAL, MC33078, , 2 U1, U6
IC-000051-00 OPTO ISOLATOR, , MOC8101, , 2 U15, U17
IC-000053-30 TIMER, DUAL, LM556, , 1 U14
IC-000054-30 COMPARATOR, QUAD, LM339AM, SMT, 1 U13
IC-000073-30 TRANSCONDUCTANCE OPAMP, DUAL, LM13600M, , 1U3
IC-000133-30 COMPARATOR, SINGLE, LM311, SMT, 4 U4, U5, U8, U9
IC-000134-00 DRIVER, MOSFET, IR2110, , 1 U18
IC-000135-00 TOP SWITCH, , TOP210, , 1 U16
IC-005532-OP OPAMP, DUAL, NE5532, , 2 U2, U7
MS-000048-HS HEAT SINK, TO-220, 1.375" X 0.86" X 0.395", LONG TAB, PLUG-IN 1 REF: Q91
MS-000115-30 FUSE, 1.0A, 24V, 1206, SLO 1 R314
MS-150250-FU FUSE, 15A, 250V, 0.25" X 1.25", FAST 1F1
