PL3 Series Service Manual 107
TD-000274-00 Rev. A
PA-000017-00 LED ASSY, GREEN, SPACER, , 4 LD3, LD4, LD8, LD9
PA-000018-00 LED ASSY, YELLOW, SPACER, , 1 LD6
PA-000043-00 PLATE ASSY, PLX, OUTPUT, , 1 J12
PC-003606-00 MAIN, PL2/PL2A, , , (ECO IN PROCESS) 1
PL-000098-00 INSULATOR, TRANSISTOR, 0.85" X 1.09", THERMALLY CONDUCTIVE, TO-220, 4
PL-000114-00 INSULATOR, IGBT/RECTIFIER, 1.25" X 3.20", THERMALLY CONDUCTIVE, , 2
PL-000117-00 INSULATOR, TRANSISTOR, , THERMALLY CONDUCTIVE, , 1
PL-000126-00 SPRING SEAT, TRANSISTOR, PLX, NYLON, , 9
PL-000128-00 SPACER, T-1 3/4 LED, 0.276", PLASTIC, BLACK, 2 REF: R30, R155
PL-000135-00 INSULATOR, TRANSISTOR, 1.25" X 1.75", MICA, , 1 REF: Q96, Q97
PL-000138-00 SPACER, T-1 LED, 0.52", PLASTIC, BLACK, 6 REF: LD1, LD2, LD5, LD7,
LD10, LD11
PT-150000-AT TRIM, 500, 20 PCNT, 0.15W, , 2 VR43, VR166
PT-310005-00 GAIN, 10K, 20 PCNT, 0.2W, 21 DETENT, 16MM LENGTH 2 VR2, VR121
QD-000014-QD DIODE RECTIFIER ULTRAFAST, 200V, 15A, , MUR1520, TO-220, 35NS 8 D21, D22, D46, D47, D74, D75, D80, D81
QD-000021-QD DIODE ZENER, 10V, , 1W, 1N4740A, DO-41, 3 D7, D32, D88
QD-000031-QD MOSFET N-CHANNEL, 60V, 50A, 150W, MTP45N06, TO-220, 4 Q38, Q41, Q83, Q86
QD-000042-00 DIODE RECTIFIER ULTRAFAST, 400V, 3A, , MUR440, DO-201AD, 50NS 2 D70, D71
QD-000062-10 TRANSISTOR NPN, 40V, 0.2A, 1.5W, 2N3904, TO-92, 2 Q20, Q65
QD-000063-10 TRANSISTOR PNP, 40V, 0.2A, 1.5W, 2N3906, TO-92, 2 Q21, Q66
QD-000076-00 TRANSISTOR NPN, 250V, 8A, 50W, MJE15032, TO-220, 2 Q27, Q72
QD-000077-00 TRANSISTOR PNP, 250V, 8A, 50W, MJE15033, TO-220, 2 Q26, Q71
QD-000080-20 DIODE ZENER, 11V, , 1W, 1N4741A, DO-41, 2 D95, D96
QD-000102-30 DIODE, 75V, 0.075A, , IMBD4148, SOT-23, 4NS 46 D1–D5, D8–D12, D14, D15, D17, D18, D23–D30, D33–D37, D39, D40, D42, D43,
D48–D52, D55, D59, D63–D65, D67, D69, D89–D91
QD-000103-30 TRANSISTOR NPN, 40V, 0.2A, 0.2W, MMST3904, SOT-23, 24 Q5, Q8, Q9, Q13, Q15, Q18, Q25, Q30, Q32, Q49, Q50, Q53, Q54, Q58, Q60,
Q63, Q70, Q75, Q77, Q89, Q90, Q92, Q93, Q95
QD-000104-30 TRANSISTOR PNP, 40V, 0.2A, 0.2W, MMST3906, SOT-23, 34 Q1–Q4, Q6, Q10–Q12, Q14, Q23, Q24, Q31, Q33, Q42–Q48, Q51, Q55–Q57, Q59,
Q68, Q69, Q76, Q78, Q87, Q88, Q94, Q98, Q99
QD-000105-30 TRANSISTOR NPN, 300V, 0.2A, 0.2W, MMBTA42, SOT-23, 4 Q7, Q16, Q52, Q61
QD-000106-30 TRANSISTOR PNP, 300V, 0.2A, 0.2W, MMBTA92, SOT-23, 2 Q17, Q62
QD-000108-30 DIODE, 200V, 0.2A, , BAS21, SOT-23, 50NS 8 D13, D16, D38, D41, D61, D68, D78, D79
QD-000110-30 DIODE ZENER, 6.2V, , 0.3W, BZX84C6V2, SOT-23, 1 D56
QD-000113-30 DIODE ZENER, 10V, , 0.3W, BZX84C10, SOT-23, 1 D66
QD-000115-30 DIODE RECTIFIER ULTRAFAST, 600V, 1A, , MURS160T3, SMB, 75NS 3 D58, D60, D86
QD-000116-30 DIODE RECTIFIER ULTRAFAST, 200V, 1A, , MURS120, SMB, 35NS 5 D62, D76, D77, D82, D83
QD-000152-10 DIODE ZENER, 12V, , 1W, 1N4742A, DO-41, 1 D57
QD-000153-00 DIODE RECTIFIER ULTRAFAST, 400V, 30A, , APT30D40B, TO-247AD, 70NS 4 D72, D73, D84, D85
QD-000154-00 TRANSISTOR NPN, 230V, 1A, 20W, 2SC4793, TO-220, 2 Q19, Q64
QD-000155-00 TRANSISTOR PNP, 230V, 1A, 20W, 2SA1837, TO-220, 2 Q22, Q67
QD-000156-00 TRANSISTOR PNP, 100V, 3A, 40W, TIP32C, TO-220, 1 Q91
QD-000169-00 IGBT, 600V, 55A, 200W, IRG4PC50U, TO-247, 2 Q96, Q97
QD-000170-00 BRIDGE RECTIFIER, , , , 600V 50A, , IN-LINE 1 BR1
QD-000184-00 LED ORANGE, , , , , T-1, 3 LD1, LD2, LD7
QD-000187-00 LED BLUE, , , , , T-1, 1 LD11
QD-000191-00 LED RED SUPER BRIGHT, , , , , T-1, 2 LD5, LD10
QD-000287-10 DIODE ZENER, 3.9V, 5 PCNT, 0.25W, DO-35, , 2 D6, D31
QD-001943-PN TRANSISTOR PNP, 230V, 15A, 150W, 2SA1943-R, TO-264, 8 Q28, Q34, Q36, Q39, Q73, Q79, Q81, Q84
QD-004744-ZA DIODE ZENER, 15V, 5 PCNT, 3W, , , 3 D53, D54, D87
QD-005200-NP TRANSISTOR NPN, 230V, 15A, 150W, 2SC5200, TO-264, 8 Q29, Q35, Q37, Q40, Q74, Q80, Q82, Q85
QD-005402-DX DIODE, 200V, 3A, , 1N5402, DO-27, 4 D19, D20, D44, D45
RE-.04703-10 0.47, 5 PCNT, 2W, METAL OXIDE FP, MINI, 32 R88, R89, R91, R92, R94, R95, R97, R99, R102, R103, R107, R108, R111–
R114, R211, R212, R214, R215, R217, R218, R220, R222, R225, R226, R230,
R231, R234–R237
RE-.15002-10 1.5, 5 PCNT, 2W, METAL OXIDE FP, MINI, 5 R115, R116, R238, R239, R269
RE-.56002-10 5.6, 5 PCNT, 2W, METAL OXIDE FP, MINI, 7 R80, R98, R203, R221, R354, R355, R373
RE-000210-NR NTC, 10 OHMS, 15 AMPS, , , INRUSH LIMIT 1 R324
RE-000230-NR NTC, 10K, , 15 PCNT, , -4.4 PCNT PER C 2 R30, R155
RE-001003-30 10, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 4 R353, R356, R358, R359
RE-001502-10 15, 5 PCNT, 2W, METAL OXIDE FP, MINI, 13 R85, R86, R87, R90, R93, R208–R210, R213, R216, R350, R367, R368
RE-003921-30 39.2, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 6 R246–R249, R349, R357
RE-004752-30 47.5, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R100, R110, R223, R233, R308, R309, R312, R313
RE-005605-EM 56, 5 PCNT, 2W, METAL OXIDE, , 1 R372
RE-007502-30 75, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R5, R6, R70, R71, R123, R124, R193, R194
PCB Assembly PL325 (230V) continued
QSC Part # Description Qty. Reference Comments
