Q24/Q48 Tape Library Installation and Operations Manual
Power button: Pressing the button will initiate a controlled power down of the library (soft power down)
3
LED <READY> (green): is illuminated during power on; blinking during tape or library media changer
activity.
4
LED <CLEAN> (amber): is illuminated when the tape drive has determined that a cleaning tape should be
used. Cleaning is only necessary when the library directs to do so. Additional cleaning is not necessary.
5
LED <ATTENTION> (amber): is illuminated when the library has detected a condition that requires
attention by the operator.
6
LED <ERROR> (amber): is illuminated when an unrecoverable tape drive or library error occurs. A
corresponding error message is shown on the LCD screen.
<UP> button [◄]: is used to navigate backward through menu items.
]: is used to cancel a user action and return to the last menu item.
<DOWN> button [►]: is used to navigate forward through menu items.
<ENTER> button [↵]: is used to enter to a sub menu or execute an action.
11
Operator control panel (OCP) consisting of a 128 x 64 pixel screen. The OCP displays actions and status
information, menu items or error messages relevant to the operational mode.
Left magazine with mail slot(s)
Figure 1 Q24 / Q48 front panel control, indicators and magazines
© C
opyright QUALSTAR 2015 4
