Name The name of the partition.
Mode The current mode of the partition (Online or Offline).
Model The library model emulated by the partition.
DriveModel The tape drive model emulated by the virtual drives in the partition.
Drives The number of virtual tape drives in the partition.
HostMapping The current state of host mapping for the partition (Yes or No). If no hosts have
been mapped, click Map to map hosts to partitions (see Remote Host Mapping on
page 238).
Media The number of virtual tape cartridges in the partition. If no cartridges have been
created, click Create to add media (see Media Add on page 229).
Slots The number of storage slots in the partition.
Deduplication The data deduplication state of the partition (Enabled or Disabled).
AutoExport Auto export state (Enabled or Disabled).
Replication The current state of replication for the partition:
l Enabled - Replication is enabled.
l Send/ReceiveSyncID - Cartridge Based Replication is enabled.
l Configure - Click to configure replication for the partition (see Partitions on page
220)
l Scheduled - Replication is scheduled for the partition. Click to view or modify
the schedule (see Scheduling a Share or Partition for Replication on page 283).
Targets The targets the partition is configured to replicate to.
AdditionalInformation
l Click a column heading to sort the rows in the table by that column. Click the column heading again to
reverse the sort order.
l Click the Information button [i] next to a partition to display detailed information about the partition and
recent replication activity.
AddingaVTLPartition
Add a VTL partition to present the storage capacity of the DXi6900 as a VTL partition that is compatible with
standard backup applications. You can add up to 64 partitions. When you add a partition, you must specify
