Quantum DXi6900

Chapter 2: Basic Operations
Locating DXi6900 Serial Numbers
Quantum DXi6900 User’s Guide 63
l The system serial number is located on the pull-out information tag on the front of the Node (see Figure
33 below). The text ServiceCallSystemSerialNumber appears on the label. The system serial
number includes the letters BVWS (DXi6900-S), BVWG2 (DXi6900 G2) or BVW (DXi6900 G1)
l The Node serial number is located to the left of the SAS ports on the rear of the Node. It is the same as
the Node service tag.
l The Array module (RBOD) and Expansion module (EBOD) serial number is located on front top of the
module and on the rear lip of the module.
Note:The system serial number also appears on the location ID label that is affixed to the lip on the
rear of the Node and each Expansion module.
Figure33:DXi6900 Node Information Tag
1
1-InformationTagPulloutwithSystemSerialNumber
