Quantum QX Series User Manual

Chapter 1: Components
QXS-4 Series and StorNext Storage
QX and QXS Setup Guide 10
l QXS-2400 System
o
2U24-drive chassis
o
SFF drives (2.5 inch)
l QXS-5600 System
o
4U56-drive chassis
o
LFF drives (3.5 inch)
o
Drives not installed (must be installed on site)
Note:Quantum no longer ships the following StorNext QX systems.
l QX-1200 System
o
2U12-drive chassis
o
LFF drives (3.5 inch)
l QX-2400 System
o
2U24-drive chassis
o
SFF drives (2.5 inch)
Note:The 2U12, 2U24, 2U48, and 4U56 drive chassis support installation of hard-disk drives (HDDs)
and solid-state disks (SSDs). The drive chassis can have all HDDs or SSDs installed, or a mixture of
HDDs and SSDs.
BezelSub-Assembly
The drive chassis include a bezel sub-assembly that attaches to the front panel of the chassis. The bezel,
comprised of a vented cover attached to an EMI shield, is pre-assembled and packed within a box contained
in the chassis master shipping container. Instructions for attaching/removing the bezel are provided in the
QXS Storage Bezel Installation Guide.
LEDDescriptions
LEDs for drive chassis are described here:
LEDs for 12-, 24-, 48-Drive Systems on page 158
12-, 24-, 48-Drive Expansion Chassis Rear Panel LEDs on page 174
LEDs for 56-Drive RAID Chassis (4U56) on page 175
