Quantum QX Series User Manual

Chapter 6: LEDDescriptions
LEDs for 56-Drive RAID Chassis (4U56)
QX and QXS Setup Guide 180
DrivemoduleLEDbehavior LFFdrives
Description State Color Action
Drive failed Fault or failure Green
1
On
Amber On
Fault and remove drive Green On
Amber On
Fault and identify drive Green On
Amber On
Fault, identify, and remove drive Green On
Amber Blink
Blue On
1
This color may or may not illuminate.
DrivegroupLEDbehavior LFFdrives
Description State Color Action
FTOL On (operating normally) Green On
Drive group activity Drive group is reconstructing Green Blink
Drive group is initializing Green Blink
Drive group degraded Drive group is critical/down See note 1 below
1
Individual drives will display fault LEDs.
Table57:LEDs: Drive groups in LFF chassis
RAID Chassis LEDs Rear Panel Layout
The diagram and table below display and identify important component items that comprise the rear panel
layout of the 56-drive RAID Chassis. Diagrams and tables on the following pages describe rear panel LED
behavior.
